HDSM-283F
RoHS
RoHS compliant
RoHS compliantPackage 12-SMD, No Lead, 11 Pads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED DISPLAY, SMD, 7MM, YLW, CC
PDF
/
Buying Options
Total Price: USD $2.78
Unit Price: USD $2.7808
≥1 USD $2.7808
≥10 USD $1.96504
≥100 USD $1.609784
≥500 USD $1.357066
Inventory: 1176
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Package / Case 12-SMD, No Lead, 11 Pads
Number of Pins 11
Technical
Packaging Tape & Reel (TR)
Published 2010
Size / Dimension 0.425 Hx0.295W x 0.124 D 10.80mmx7.50mmx3.15mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Terminal Finish Tin (Sn)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Yellow
Subcategory LED Displays
Number of Functions 1
Depth 10.8mm
Operating Supply Voltage 2.1V
Number of Elements 9
Power Dissipation-Max 65mW
Element Configuration Common Cathode
Power Dissipation 65mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 8 mcd
Millicandela Rating 8mcd
Wavelength - Peak 591nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.6V
Number of Characters 1
Digit/Alpha Size 0.28 7.00mm
Common Pin Common Cathode
Dominant Wavelength 589 nm
Dimensions
Height 10.795mm
Viewing Area (height) 7mm
Character Height 7mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
