HDSM-281C

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 12-SMD, No Lead, 11 Pads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description AVAGO TECHNOLOGIES HDSM-281C 7-Segment LED Display, Surface Mount, 1, 7 mm, Red, Common Anode, 7.5 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $2.78
Unit Price: USD $2.7808
≥1 USD $2.7808
≥10 USD $1.96504
≥100 USD $1.609784
≥500 USD $1.357066
Inventory: 7740
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Surface Mount
Package / Case 12-SMD, No Lead, 11 Pads
Number of Pins 11

Technical

Packaging Tape & Reel (TR)
Published 2008
Size / Dimension 0.425 Hx0.295W x 0.124 D 10.80mmx7.50mmx3.15mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Positions 1
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Red
Depth 10.8mm
Number of Elements 9
Power Dissipation-Max 65mW
Element Configuration Common Anode
Power Dissipation 65mW
Voltage - Forward (Vf) (Typ) 2V
Forward Current 20mA
Current - Test 20mA
Forward Voltage 2.6V
Luminous Intensity 7.5 mcd
Millicandela Rating 7.5mcd
Illumination Color Red
Wavelength - Peak 632nm
Display Type 7-Segment
Reverse Voltage 5V
Wavelength 634 nm
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.28 7.00mm
Common Pin Common Anode
Dominant Wavelength 624 nm
Character Width 4.6mm

Dimensions

Height 10.795mm
Length 7.5mm
Width 7.493mm
Viewing Area (height) 7mm
Character Height 7mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
