ADSP-H8L3

Broadcom Limited
RoHS
/
Package 16-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description 7SEG DISPLAY 1DIGIT ORN 0.8" CC
PDF
/
Inventory: 6608
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 19.9898mm
Height 27.7114mm

Technical

Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 610nm
Millicandela Rating 35mcd
Luminous Intensity 35 mcd
Forward Voltage 2V
Current - Test 20mA
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 52mW
Color Orange
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 1.091 Hx0.787W x 0.394 D 27.70mmx20.00mmx10.00mm
Published 2012
Packaging Tube

Physical

Package / Case 16-DIP (0.600, 15.24mm)
