ADSP-H3L3
RoHS
/
Package 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
7SEG DISPLAY 1DIGIT ORN 0.36" CC
PDF
/
Inventory: 1484
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7.493mm
Height 13.9954mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.36 9.14mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 610nm
Millicandela Rating 13mcd
Luminous Intensity 13 mcd
Forward Voltage 2V
Current - Test 20mA
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 52mW
Color Orange
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
Published 2012
Packaging Tube
Physical
Package / Case 10-DIP (0.200, 5.08mm)
