5082-7666
RoHS
/
Package 14-DIP (0.300, 7.62mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 6LED Yellow 14-Pin DIP
PDF
/
Inventory: 2163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Copper, Silver, Tin
Mount Through Hole
Package / Case 14-DIP (0.300, 7.62mm), 12 Leads
Number of Pins 14
Technical
Packaging Tube
Published 2014
Size / Dimension 0.750 Hx0.500W x 0.250 D 19.05mmx12.70mmx6.35mm
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Yellow
HTS Code 8531.20.00.40
Subcategory LED Displays
Number of Functions 0.5
Depth 12.7mm
Number of Elements 6
Configuration SEPARATE, 0.5 DIGIT WITH DECIMAL POINT
Power Dissipation 80mW
Voltage - Forward (Vf) (Typ) 2.2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 840 μcd
Millicandela Rating 0.84mcd
Wavelength - Peak 583nm
Display Type 7-Segment
Reverse Voltage 40V
Forward Voltage-Max 2.5V
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.43 11.00mm
Common Pin Universal
Dominant Wavelength 586 nm
Character Width 10.9mm
Dimensions
Height 19.05mm
Viewing Area (height) 10.31mm
Compliance
RoHS Status RoHS Compliant
