5082-7651
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES 5082-7651 7-Segment LED Display, 1, 10.9 mm, Red, Common Anode, 1.115 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.65965
≥1 USD $1.65965
≥10 USD $1.36135
≥100 USD $1.31955
≥500 USD $1.2768
≥1000 USD $1.23405
Inventory: 5662
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Plating Copper, Silver, Tin
Mount Through Hole
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Number of Pins 14
Technical
Packaging Tube
Published 2006
Size / Dimension 0.750 Hx0.500W x 0.250 D 19.05mmx12.70mmx6.35mm
Character Width 7.01mm
Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.43 11.00mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 30V
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 635nm
Millicandela Rating 1.12mcd
Luminous Intensity 1.115 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 105mW
Element Configuration Common Anode
Number of Elements 8
Depth 12.7mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 10.9mm
Viewing Area (height) 10.92mm
Height 19.05mm
