RoHS
RoHS compliant
RoHS compliantPackage 25-DIP Module
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
RGB 7-SEGMENT 1" COMMON ANODE
PDF
/
Buying Options
Total Price: USD $34.28
Unit Price: USD $34.282445
≥1 USD $34.282445
≥200 USD $13.679105
≥500 USD $13.222216
≥1000 USD $12.996397
Inventory: 2401
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 24.003mm
Height 35.5092mm
Technical
Common Pin Common Anode
Digit/Alpha Size 1.00 25.40mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 616nm Red 523nm Green 468nm Blue
Millicandela Rating 244mcd Red, 552mcd Green, 100mcd Blue
Luminous Intensity 100 mcd
Forward Voltage 3.4V
Current - Test 20mA Red 20mA Green 20mA Blue
Voltage - Forward (Vf) (Typ) 2.1V Red 3.5V Green 3.4V Blue
Power Dissipation-Max 150mW
Color Red, Green, Blue (RGB)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.398 Hx0.945W x 0.343 D 35.50mmx24.00mmx8.70mm
Packaging Bulk
Physical
Package / Case 25-DIP Module
Supply Chain
Factory Lead Time 2 Weeks
