LQ104S1DG21
RoHS
/
Package /
Category Optoelectronics / Display Modules - LCD, OLED, Graphic
Description
LCD TFT 10.4" 800X600 SVGA
PDF
/
Inventory: 5506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Number of Pins 41
Technical
Packaging Box
Published 2006
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Subcategory Displays
Supply Voltage 5V
Reach Compliance Code unknown
Operating Temperature (Max) 65°C
Operating Temperature (Min) -10°C
Interface Parallel, 18-Bit (RGB)
Display Type TFT - Color
Viewing Area 211.20mm W x 158.40mm H
Display Mode Transmissive
Backlight CCFL
Dot Pixels 800 x 600 (SVGA)
Diagonal Screen Size 10.4 264.16mm
Graphics Color Red, Green, Blue (RGB)
Dot Pitch 0.26mm Wx0.26mm H
Resolution (height) 600 pixel
Resolution (width) 800 pixel
Diagonal Size 10.4 in
Dimensions
Height 15.5mm
Length 246mm
Width 179mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
