LQ084V3DG02
RoHS
/
Package Module
Category Optoelectronics / Display Modules - LCD, OLED, Graphic
Description
SHARP LQ084V3DG02 TFT LCD, 8.4 ", 640 x 480, VGA, Landscape, RGB, 3.3V
PDF
/
Inventory: 6506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Viewing Area (height) 128.16mm
Width 199.5mm
Height 149.5mm
Technical
Viewing Area (width) 170.88mm
Brightness 400 cd/m^2
Contrast Ratio 600:1
Diagonal Size 8.4 in
Resolution (width) 640 pixel
Resolution (height) 480 pixel
Backlight Type LED
Dot Pitch 0.27mm Wx0.27mm H
Graphics Color Red, Green, Blue (RGB)
Diagonal Screen Size 8.4 213.36mm
Dot Pixels 640 x 480 (VGA)
Touchscreen No
Backlight LED - White
Display Mode Transmissive
Viewing Area 170.88mm W x 128.16mm H
Display Type TFT - Color
Response Time 26 ms
Interface Parallel, 18-Bit (RGB)
Depth 11.6mm
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2007
Physical
Package / Case Module
