LQ043T1DG29
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Display Modules - LCD, OLED, Graphic
Description
4.3in TFT 480x272Pixels Serial 360cd/m2 LED Backlight -10C to 70C 67-Pin
PDF
/
Inventory: 6530
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Diagonal Size 4.3 in
Resolution (width) 480 pixel
Resolution (height) 272 pixel
Backlight Type LED
Dot Size 0.20mm Wx0.20mm H
Graphics Color Red, Green, Blue (RGB)
Diagonal Screen Size 4.3 109.22mm
Background Color White
Dot Pixels 480 x 272
Backlight LED - White
Display Mode Transmissive
Viewing Area 95.04mm W x 53.86mm H
Display Type TFT - Color
Interface Parallel/Serial
Operating Supply Voltage 3.3V
Min Operating Temperature -10°C
Max Operating Temperature 70°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2013
Physical
Number of Pins 67
Supply Chain
Factory Lead Time 20 Weeks
