IS01BBFRGB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Display Modules - LCD, OLED, Graphic
Description
LCD 36X24 RGB DSPLY WD SCRN
PDF
/
Buying Options
Total Price: USD $75.79
Unit Price: USD $75.788465
≥1 USD $75.788465
≥200 USD $30.240026
≥500 USD $29.230406
≥1000 USD $28.730191
Inventory: 5988
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Technical
Published 2013
Series SmartDisplay?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Subcategory Displays
Supply Voltage 5V
Operating Temperature (Max) 60°C
Operating Temperature (Min) -20°C
Interface SPI
Display Type FSTN - Film Super-Twisted Nematic
Overall Height 8.6mm
Viewing Area 14.40mm W x 11.80mm H
Display Mode Transflective
Backlight LED - Red/Green/Blue
Dot Pixels 36 x 24
Background Color Red/Green/Blue
Diagonal Screen Size 0.7 17.78mm
Graphics Color Black
Dot Size 0.20mm Wx0.29mm H
Overall Length 17.8mm
Dot Pitch 0.22mm Wx0.31mm H
Backlight Type LED
Resolution (height) 24 pixel
Resolution (width) 36 pixel
Diagonal Size 0.7 in
Viewing Area (width) 14.4mm
Overall Depth 17.2mm
Dimensions
Viewing Area (height) 11.8mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
