NHD-0420DZW-AY5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Display Modules - LCD, OLED Character and Numeric
Description
LCD MODULE 80 DIG 20 X 4 PASSIVE
PDF
/
Buying Options
Total Price: USD $33.47
Unit Price: USD $33.4664
≥1 USD $33.4664
≥10 USD $31.45824
≥100 USD $29.45096
≥500 USD $28.431392
Inventory: 1132
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Character Format 5 x 8 Dots
Text Color Yellow
Character Size 4.75mm Hx2.90mm W
Outline L x W x H 98.00mm x 60.00mm x 10.00mm
Display Format 20 x 4
Dot Size 0.54mm Wx0.55mm H
Background Color Black
Backlight Without Backlight
Display Mode Passive
Viewing Area 77.00mm L x 25.20mm W
Number of Characters 80
Display Type OLED
Viewing Angle 80 °
Interface Parallel/Serial
Operating Supply Voltage 3V
Voltage - Supply 3V~5.3V
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Not For New Designs
Published 2009
Operating Temperature -40°C~80°C
Physical
Mount Wire
Supply Chain
Factory Lead Time 18 Weeks
