NHD-0220WH-MTFH-JT#E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Display Modules - LCD, OLED Character and Numeric
Description
LCD MOD 40DIG 20X2 TRANSFLCT WHT
PDF
/
Buying Options
Total Price: USD $25.73
Unit Price: USD $25.7312
≥1 USD $25.7312
≥10 USD $24.18768
≥100 USD $22.64328
≥500 USD $21.356896
≥1000 USD $20.327648
≥3000 USD $19.298541
Inventory: 76
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Controller Type KS0066U
Character Format 5 x 8 Dots
Text Color Black
Backlight Type LED
Character Size 9.22mm Hx4.84mm W
Outline L x W x H 146.00mm x 43.00mm x 13.70mm
Display Format 20 x 2
Dot Size 0.92mm Wx1.10mm H
Background Color White
Backlight LED - White
Display Mode Transflective
Viewing Area 123.00mm L x 23.00mm W
Number of Characters 40
Display Type FSTN - Film Super-Twisted Nematic
Interface Parallel
Operating Supply Voltage 5V
Voltage - Supply 4.5V~5.5V
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Published 2009
Operating Temperature -20°C~70°C
Supply Chain
Factory Lead Time 14 Weeks
