LCM-S01602DTR/B
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Optoelectronics / Display Modules - LCD, OLED Character and Numeric
Description
LCD Character Display Modules & Accessories InfoVue Std 16x2 TN, Reflective
PDF
/
Inventory: 3592
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 36mm
Length 85mm
Height 8.8mm
Technical
Character Format 5 x 8 Dots
Backlight Type LED
Character Size 5.56mm Hx2.96mm W
Outline L x W x H 84.00mm x 44.00mm x 8.80mm
Display Format 16 x 2
Dot Size 0.56mm Wx0.66mm H
Background Color Grey
Backlight Without Backlight
Display Mode Reflective
Viewing Area 66.00mm L x 16.00mm W
Number of Characters 32
Display Type TN - Twisted Nematic
Interface Parallel
Voltage - Supply 5V
Min Operating Temperature 0°C
Max Operating Temperature 50°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2000
Packaging Bulk
Operating Temperature 0°C~50°C
Physical
Number of Pins 14
Package / Case Module
Mount Screw
Supply Chain
Factory Lead Time 11 Weeks
