Package Module
Category Optoelectronics / Display Modules - LCD, OLED Character and Numeric
Description LCD Character Display Modules & Accessories InfoVue Std 16x2 STN, Transf w/bklght
PDF
/
Inventory: 4297
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Package / Case Module

Technical

Operating Temperature 0°C~50°C
Packaging Bulk
Published 2000
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Supply 5V
Interface Parallel
Optoelectronic Device Type 5X8 DOT MATRIX DISPLAY
Display Type STN - Super-Twisted Nematic
Number of Characters 32
Viewing Area 99.00mm L x 24.00mm W
Display Mode Transflective
Backlight LED - Yellow/Green
Background Color Grey
Dot Size 1.16mm Wx1.16mm H
Display Format 16 x 2
Outline L x W x H 122.00mm x 44.00mm x 13.00mm
Character Size 9.63mm Hx4.84mm W
Backlight Type LED
Character Format 5 x 8 Dots

Dimensions

Height 13mm
Length 122mm
Width 44mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
