LCM-H01601DSF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Display Modules - LCD, OLED Character and Numeric
Description
LCD Character Display Modules & Accessories InfoVue H Tmp 16x1 STN, Transf w/bklght
PDF
/
Buying Options
Total Price: USD $10.34
Unit Price: USD $10.34
≥1 USD $10.34
≥10 USD $7.8452
Inventory: 114
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2002
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Supply 4.7V~5.3V
Interface Parallel, 8-Bit
Display Type STN - Super-Twisted Nematic
Number of Characters 16
Viewing Area 66.00mm L x 16.00mm W
Display Mode Transflective
Backlight LED
Background Color Grey
Dot Size 0.55mm Wx0.75mm H
Display Format 16 x 1
Outline L x W x H 80.00mm x 36.00mm x 12.70mm
Character Size 6.56mm Hx3.07mm W
Character Format 5 x 8 Dots
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
