1825286-4
RoHS
/
Package /
Category Switches / DIP Switches
Description
Switch DIP ON OFF SPST 4 Recessed Rocker 0.025A 24VDC Gull Wing 2.54mm SMD
PDF
/
Inventory: 4376
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 11.1252mm
Height 6.86mm
Technical
Washable Yes
Current Rating (Max) 25mA
Contact Rating (Current) 100mA
Max Voltage Rating (DC) 24V
Throw Configuration SPST
ELV Compliant
Lead Length 3.8608mm
Housing Color Black
Orientation Straight
Pitch 1.27mm
Voltage - Rated DC 50V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Positions 4
Type Switch
Termination Gull Wing
Physical
Housing Material Polyphenylene
Mount Surface Mount
Contact Plating Gold
