RoHS
/
Package /
Category Switches / DIP Switches
Description
DIP Switches / SIP Switches 7 POSITION EXT ACT
PDF
/
Buying Options
Total Price: USD $17.1
Unit Price: USD $17.10285
≥1 USD $17.10285
≥10 USD $14.0334
≥100 USD $13.5945
≥500 USD $13.15655
≥1000 USD $12.71765
Inventory: 1498
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Height Above Board 0.232 5.90mm
Actuator Length 990μm
Length 0.778 19.76mm
Technical
Actuator Level Raised
Washable Yes
Number of Switch Sections 7
Mechanical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Electrical Life 1,000 Cycles
ELV Non-Compliant
Contact Resistance 50mOhm
Circuit SPST
Housing Color Grey
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 400mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated 24VDC
Number of Positions 7
Type Switch
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series ADE
Published 2004
Packaging Tube
Operating Temperature -30°C~85°C
Physical
Actuator Material Polyamide
Body Material Polyphenylene Sulfide (PPS)
Housing Material Polyester
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
