A6SR-4101-P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
DIP Switches / SIP Switches SMT Low Profile DIP Switch
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.804
≥1 USD $1.804
≥10 USD $1.75648
≥100 USD $1.597728
≥500 USD $1.388024
≥1000 USD $1.257942
Inventory: 739
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Weight 480mg
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Published 2009
Series A6SR
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Number of Positions 4
Voltage - Rated 24VDC
Additional Feature LOW PROFILE
Voltage - Rated DC 24V
Pitch 0.100 2.54mm Full
Packing Method TAPE AND REEL
Orientation Straight
Terminal Pitch 2.54mm
Current Rating 25mA
Contact Finish Gold
Termination Style Gull Wing
Body Breadth 6 mm
Actuator Type Piano
Circuit SPST
Contact Resistance 200mOhm
Contact Current(DC)-Max 0.025A
Electrical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 1000 cycles
Number of Switch Sections 4
Washable No
Actuator Level Flush, Recessed
Dimensions
Length 0.396 10.06mm
Body Height 5mm
Actuator Length 0m
Height Above Board 0.197 5.00mm
Compliance
RoHS Status RoHS Compliant
