A6SN-1104
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
DIP Switches / SIP Switches 1P Knife-Edge, 2.3mm Slide SMT Raised-Act
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.6632
≥1 USD $1.6632
≥10 USD $1.62008
≥100 USD $1.473472
≥500 USD $1.280048
≥1000 USD $1.160042
≥3000 USD $1.080042
Inventory: 1076
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height Above Board 0.214 5.45mm
Actuator Length 1mm
Body Height 4.25mm
Length 0.176 4.48mm
Technical
Actuator Level Raised
Washable Yes
Switch Action LATCHED
Number of Switch Sections 1
Switch Type SLIDE DIP SWITCH
Max Voltage Rating (DC) 24V
Electrical Life 1,000 Cycles
Max Current Rating 25mA
Contact Current(DC)-Max 0.025A
Contact Resistance 200mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 4.48 mm
Termination Style Gull Wing
Current Rating 10μA
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 3.5V
HTS Code 8536.50.90.65
Voltage - Rated 24VDC
Number of Positions 1
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series A6SN
Published 2010
Packaging Tube
Operating Temperature -30°C~85°C
Physical
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
