A6KS-102RF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
OMRON ELECTRONIC COMPONENTS A6KS-102RF Rotary Switch, A6KS Series, Non Illuminated, 25 mA
PDF
/
Buying Options
Total Price: USD $8.01
Unit Price: USD $8.008
≥1 USD $8.008
≥10 USD $7.64104
≥100 USD $6.476378
≥500 USD $6.003342
≥1000 USD $5.457575
≥3000 USD $5.05736
Inventory: 227
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height Above Board 0.118 3.00mm
Actuator Length 0m
Width 7.2mm
Length 0.283 7.20mm
Height 7.2mm
Technical
Life (Cycles) 20000 cycles
Actuator Level Flush, Recessed
Washable No
Illumination Type Illuminated
Contact Current Rating 25mA
Max Voltage Rating (DC) 24V
Throw Configuration SP10T, SPST
Electrical Life 20,000 Steps
Insulation Resistance 100MOhm
Contact Resistance 200mOhm
Circuit BCD
Actuator Type Rotary for Tool
Termination Style Gull Wing
Contact Finish Gold
Current Rating 25mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Number of Positions 10
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series A6KS
Published 2008
Packaging Tube
Operating Temperature -30°C~80°C
Physical
Weight 400mg
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 16 Weeks
