A6H8101PM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 8 Recessed Slide 0.025A 24VDC Gull Wing 1000Cycles 1.27mm SMD T/R
PDF
/
Buying Options
Total Price: USD $2.84
Unit Price: USD $2.843741
≥1 USD $2.843741
≥200 USD $1.10021
≥500 USD $1.062136
≥1000 USD $1.042443
Inventory: 5981
Minimum: 1
-
+
Technical Details
Dimensions
Height Above Board 0.061 1.55mm
Length 0.448 11.39mm
Compliance
RoHS Status RoHS Compliant
Technical
Actuator Level Flush, Recessed
Washable No
Mechanical Life 1,000 Cycles
Electrical Life 1,000 Cycles
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Pitch 0.050 1.27mm Half
Current Rating (Amps) 25mA
Voltage - Rated 24VDC
Number of Positions 8
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series A6H
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
