A6E-3104-N
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
DIP SWITCH 3POS RAISED ACTUATOR
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.6048
≥1 USD $2.6048
≥10 USD $2.45256
≥100 USD $2.070244
≥500 USD $1.932207
≥1000 USD $1.751754
≥3000 USD $1.624357
Inventory: 320
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Height Above Board 0.277 7.05mm
Body Height 5.842mm
Length 0.354 8.99mm
Technical
Actuator Level Raised
Washable No
Actuator Color WHITE
Switch Type SLIDE DIP SWITCH
Mechanical Life 1,000 Cycles
Electrical Life 1,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Contact Current(DC)-Max 0.025A
Insulation Resistance 100000000Ohm
Contact Resistance 0.2mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 9.906 mm
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Number of Positions 3
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series A6E-N
Published 2013
Packaging Tube
Operating Temperature -20°C~70°C
Physical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
