A6D-8100
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
OMRON ELECTRONIC COMPONENTS A6D8100 DIP / SIP Switch, A6D Series, SPST, DIP Sealed, Through Hole, 25 mA, 24 VDC
PDF
/
Buying Options
Total Price: USD $3.87
Unit Price: USD $3.872
≥1 USD $3.872
≥10 USD $3.710538
≥100 USD $3.387806
≥500 USD $2.936138
≥1000 USD $2.661877
≥3000 USD $2.468294
Inventory: 195
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Contact Material Copper, Gold
Contact Plating Copper, Gold
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case DIP
Insulation Material POLYBUTYLENE TEREPHTHALATE
Weight 1.700008g
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Published 1998
Series A6D
JESD-609 Code e4
Feature IP64 - Dust Tight, Water Resistant
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pins
ECCN Code EAR99
Number of Positions 2
Voltage - Rated 30VDC
Additional Feature SEALED CONSTRUCTION
Voltage - Rated DC 30V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Depth 7.62mm
Current Rating 30mA
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.6 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 100mOhm
Insulation Resistance 100MOhm
Contact Current(DC)-Max 0.03A
Max Current Rating 100mA
Dielectric Withstanding Voltage 500VAC V
Electrical Life 2,000 Cycles
Number of Poles 8
Max Voltage Rating (DC) 30V
Mechanical Life 5000 cycles
Contact Current Rating 100mA
Number of Switch Sections 8
PCB Hole Count 16
Contact Function ON-OFF
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.879 22.33mm
Body Height 3.4mm
Actuator Length 0m
Height Above Board 0.173 4.40mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
