SC-2010B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH ROTARY DIP BCD 100MA 5V
PDF
/
Buying Options
Total Price: USD $2.7
Unit Price: USD $2.7016
≥1 USD $2.7016
≥10 USD $2.149136
≥100 USD $2.005872
≥500 USD $1.565001
≥1000 USD $1.364
Inventory: 182
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount PCB, Surface Mount
Mounting Type Surface Mount
Body Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2011
Series SC-2000
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Number of Positions 10
Voltage - Rated 5VDC
Voltage - Rated DC 5V
Pitch 0.100 2.54mm Full
Current Rating 100mA
Contact Finish Gold
Termination Style Gull Wing
Actuator Type Rotary for Tool
Circuit BCD
Contact Resistance 100MOhm
Insulation Resistance 1GOhm
Electrical Life 20,000 Steps
Max Voltage Rating (DC) 5V
Switch Type ROTARY CODED SWITCH
Contact Current Rating 100mA
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.393 10.00mm
Height Above Board 0.157 4.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
