SA-7151C image
Favorite
SA-7151C image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description SWITCH ROTARY DIP HEX 100MA 5V
PDF
/
Buying Options
Total Price: USD $8.98
Unit Price: USD $8.981549
≥1 USD $8.981549
≥200 USD $3.584217
≥500 USD $3.464743
≥1000 USD $3.40435
Inventory: 5136
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Polyphenylene Sulfide (PPS)

Technical

Operating Temperature -40°C~85°C
Packaging Bulk
Published 2012
Series SA-7000
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 16
Voltage - Rated 5VDC
Voltage - Rated DC 5V
Pitch 0.100 2.54mm Full
Packing Method BAG
Current Rating 100mA
Contact Finish Gold
Termination Style PC Pin
Body Breadth 7.2 mm
Actuator Type Rotary with Shaft
Circuit Hexadecimal
Contact Current(DC)-Max 0.1A
Electrical Life 10,000 Steps
Max Voltage Rating (DC) 5V
Switch Type ROTARY CODED SWITCH
Index Angle 22.5 deg
Number of Switch Sections 1
Washable No
Actuator Level Raised

Dimensions

Length 0.283 7.20mm
Body Height 8.3mm
Height Above Board 0.327 8.30mm

Compliance

RoHS Status ROHS3 Compliant
