SA-7070TB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SW ROTARY DIP HEX COMP 100MA 5V
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.467822
≥1 USD $1.467822
≥10 USD $1.28139
≥30 USD $1.118591
Inventory: 9987
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount
Housing Material POLYPHENYLENE SULPHIDE
Body Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2015
Series SA-7000
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Number of Positions 16
Voltage - Rated 5VDC
HTS Code 8536.50.90.20
Voltage - Rated DC 5V
Pitch 0.100 2.54mm Full
Current Rating 100mA
Contact Finish Gold
Termination Style Gull Wing
Body Breadth 7.2136 mm
Actuator Type Rotary for Tool
Circuit Hexadecimal Complement
Contact Resistance 0.1mOhm
Insulation Resistance 100000000Ohm
Contact Current(DC)-Max 0.001A
Electrical Life 10,000 Steps
Max Voltage Rating (DC) 5V
Switch Type ROTARY CODED SWITCH
Index Angle 22.5 deg
Washable No
Actuator Level Flush, Recessed
Dimensions
Length 0.283 7.20mm
Body Height 2.9972mm
Height Above Board 0.118 3.00mm
Compliance
RoHS Status ROHS3 Compliant
