SA-7050TB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Rotary for Tool SA-7000 16 Surface Mount Dip Switch 2.9972mm 0.1A 5V 22.5deg
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.83265
≥1 USD $4.83265
≥10 USD $3.9653
≥100 USD $3.8418
≥500 USD $3.71735
≥1000 USD $3.59385
≥1000 USD $3.2224
Inventory: 1277
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.118 3.00mm
Body Height 2.9972mm
Length 0.283 7.20mm
Technical
Actuator Level Flush, Recessed
Washable No
Index Angle 22.5 deg
Switch Type ROTARY CODED SWITCH
Electrical Life 10,000 Steps
Dielectric Withstanding Voltage 250VAC V
Contact Voltage(DC)-Max 5V
Contact Current(DC)-Max 0.1A
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Circuit Hexadecimal
Actuator Type Rotary for Tool
Body Breadth 7.1882 mm
Termination Style Gull Wing
Contact Finish Gold
Current Rating 100mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 5V
HTS Code 8536.50.90.20
Voltage - Rated 5VDC
Number of Positions 16
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series SA-7000
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Body Material Polyphenylene Sulfide (PPS)
Housing Material POLYPHENYLENE SULPHIDE
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 11 Weeks
