SA-7010B image
Favorite
SA-7010B image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description SWITCH ROTARY DIP BCD 100MA 5V
PDF
/
Buying Options
Total Price: USD $1.51
Unit Price: USD $1.509835
≥1 USD $1.509835
≥10 USD $1.297145
≥30 USD $1.164542
≥100 USD $1.020123
≥500 USD $0.958417
≥1000 USD $0.932159
Inventory: 4156
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount
Housing Material POLYPHENYLENE SULPHIDE
Body Material Polyphenylene Sulfide (PPS)

Technical

Operating Temperature -40°C~85°C
Packaging Bulk
Published 2015
Series SA-7000
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Number of Positions 10
Voltage - Rated 5VDC
HTS Code 8536.50.90.20
Voltage - Rated DC 5V
Pitch 0.100 2.54mm Full
Current Rating 100mA
Contact Finish Gold
Termination Style Gull Wing
Body Breadth 7.1882 mm
Actuator Type Rotary for Tool
Circuit BCD
Contact Resistance 0.1mOhm
Contact Current(DC)-Max 0.1A
Dielectric Withstanding Voltage 250VAC V
Electrical Life 10,000 Steps
Max Voltage Rating (DC) 5V
Switch Type ROTARY CODED SWITCH
Index Angle 36 deg
Washable No
Actuator Level Flush, Recessed

Dimensions

Length 0.283 7.20mm
Body Height 2.9972mm
Height Above Board 0.118 3.00mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
