CHS-01B1
RoHS
/
Package SMD/SMT
Category Switches / DIP Switches
Description
Switch Slide OFF ON SPST Recessed Slide 0.1A 24VDC Gull Wing SMD Bulk
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.863429
≥1 USD $0.863429
≥10 USD $0.814552
≥100 USD $0.768448
≥500 USD $0.724954
≥1000 USD $0.683917
Inventory: 1163
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.098 2.50mm
Length 0.098 2.50mm
Technical
Actuator Level Flush, Recessed
Washable No
Max Voltage Rating (DC) 24V
Throw Configuration SPST
Electrical Life 2,000 Cycles
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Pitch 0.050 1.27mm Half
Current Rating (Amps) 100mA
Voltage - Rated 6VDC
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 1
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CHS
Published 2015
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Body Material Polyphenylene Sulfide (PPS)
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 11 Weeks
