CHP-080TA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH PIANO DIP SPST 100MA 6V
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1001
Minimum: 1
-
+
Technical Details
Technical
Circuit SPST
Contact Resistance 0.05mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 0.025A
Dielectric Withstanding Voltage 500VAC V
Electrical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Contact (DC) Max Rating R Load 0.025A@24VDC
Number of Switch Sections 8
PCB Hole Count 16
Washable No
Actuator Level Raised
Solderability REFLOW
Actuator Type Piano
Termination Style J Lead
Contact Finish Gold
Current Rating 100mA
Pitch 0.050 1.27mm Half
Voltage - Rated DC 6V
Voltage - Rated 6VDC
Number of Positions 8
ECCN Code EAR99
Termination J-Hook
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series CHP
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Length 0.480 12.19mm
Body Height 4.5974mm
Height Above Board 0.181 4.60mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Body Material Polyphenylene Sulfide (PPS)
Housing Material POLYPHENYLENE SULPHIDE
Insulation Material POLYPHENYLENE SULPHIDE
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 11 Weeks
