CHP-080A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH PIANO DIP SPST 100MA 6V
PDF
/
Buying Options
Total Price: USD $6.36
Unit Price: USD $6.364939
≥1 USD $6.364939
≥200 USD $2.463
≥500 USD $2.376349
≥1000 USD $2.334336
Inventory: 936
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Body Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2015
Series CHP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination J-Hook
Number of Positions 8
Voltage - Rated 6VDC
Voltage - Rated DC 6V
Pitch 0.050 1.27mm Half
Current Rating 100mA
Contact Finish Gold
Termination Style J Lead
Actuator Type Piano
Circuit SPST
Electrical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Washable No
Actuator Level Raised
Dimensions
Length 0.480 12.19mm
Height Above Board 0.181 4.60mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
