97C10S
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $4.48
Unit Price: USD $4.483554
≥1 USD $4.483554
≥198 USD $1.789483
≥495 USD $1.729089
≥990 USD $1.700206
Inventory: 1389
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Above Board 0.063 1.60mm
Body Height 1.5mm
Width 13.9mm
Length 0.548 13.93mm
Technical
Washability SOLVENT
Actuator Level Flush, Recessed
Washable Yes
Contact Function ON-ON
Actuator Color WHITE
Number of Switch Sections 10
Switch Type SLIDE DIP SWITCH
Mechanical Life 1,000 Cycles
Dielectric Withstanding Voltage 300VAC V
Contact Current(DC)-Max 0.025A
Contact Resistance 0.1mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 4.5 mm
Termination Style Gull Wing
Contact Finish Gold
Current Rating 25mA
Orientation Vertical
Packing Method TAPE AND REEL
Pitch 0.050 1.27mm Half
Voltage - Rated DC 24V
HTS Code 8536.50.90.65
Additional Feature LOW PROFILE
Voltage - Rated 24VDC
Number of Positions 10
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Tape Seal
JESD-609 Code e4
Series 97
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Terminal Material BRASS
Body Material Polyamide (PA), Nylon
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
