90HBJ05P
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $2.91
Unit Price: USD $2.909386
≥1 USD $2.909386
≥186 USD $1.161917
≥496 USD $1.12253
≥992 USD $1.102836
Inventory: 4043
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Above Board 0.220 5.59mm
Width 14.5mm
Length 0.570 14.48mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Number of Switch Sections 5
Contact (DC) Max Rating R Load .1A@6VDC
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Contact Voltage(DC)-Max 6V
Contact Current(DC)-Max 0.1A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 7.37 mm
Termination Style J Lead
Contact Finish Gold
Current Rating 25mA
Orientation Vertical
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Terminal Finish Tin/Lead (Sn/Pb)
Number of Positions 5
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
Feature Tape Seal
JESD-609 Code e0
Series 90HB
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Thermoplastic
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
