90B08S
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Inventory: 1212
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 1995
Series 90B
JESD-609 Code e0
Feature Tape Seal
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Number of Positions 8
Terminal Finish Tin/Lead (Sn/Pb)
Voltage - Rated 24VDC
Voltage - Rated DC 24V
Pitch 0.100 2.54mm Full
Orientation Vertical
Reach Compliance Code not_compliant
Current Rating 25mA
Contact Finish Gold
Termination Style PC Pin
Body Breadth 7.366 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 0.1mOhm
Insulation Resistance 5000000000Ohm
Contact Current(DC)-Max 0.01A
Contact Voltage(DC)-Max 30V
Dielectric Withstanding Voltage 500VRMS V
Electrical Life 2,000 Cycles
Mechanical Life 2,000 Cycles
Contact Timing MAKE-BEFORE-BREAK
Contact (DC) Max Rating R Load 0.01A@30VDC
PCB Hole Count 16
Contact Function ON-OFF
Washable Yes
Actuator Level Flush, Recessed
Solderability WAVE
Washability SOLVENT
Dimensions
Length 0.870 22.10mm
Body Height 4.572mm
Height Above Board 0.195 4.95mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
