90B03T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 90B 3 Through Hole Dip Switch 4.95mm 0.1A 30V .1A@6VDC
PDF
/
Inventory: 4471
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2010
Series 90B
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Number of Positions 3
Terminal Finish Matte Tin (Sn)
Voltage - Rated 24VDC
Voltage - Rated DC 24V
Pitch 0.100 2.54mm Full
Orientation Straight
Current Rating 25mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Max Current Rating 150mA
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Contact (DC) Max Rating R Load .1A@6VDC
Number of Switch Sections 3
Washable No
Actuator Level Flush, Recessed
Dimensions
Length 0.370 9.40mm
Body Height 4.95mm
Height Above Board 0.195 4.95mm
Compliance
RoHS Status RoHS Compliant
