78RB10ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 150MA 30V
PDF
/
Buying Options
Total Price: USD $4.16
Unit Price: USD $4.1624
≥1 USD $4.1624
≥10 USD $3.9864
≥100 USD $3.639618
≥500 USD $3.154307
≥1000 USD $2.859718
≥3000 USD $2.65173
Inventory: 197
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2007
Series 78
Feature Tape Seal
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Number of Positions 10
Voltage - Rated 30VDC
HTS Code 8536.50.90.65
Voltage - Rated DC 30V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Depth 9.65mm
Current Rating 150mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.15A
Max Current Rating 150mA
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 10
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 1.080 27.43mm
Body Height 6.73mm
Actuator Length 0m
Height Above Board 0.265 6.73mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
