78RB10RAT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 10 Recessed Slide 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube
PDF
/
Inventory: 9922
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.380 9.64mm
Length 1.080 27.43mm
Technical
Actuator Level Flush, Recessed
Washable No
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Electrical Life 10,000 Cycles
Max Current Rating 150mA
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 150mA
Orientation Right Angle
Pitch 0.100 2.54mm Full
Voltage - Rated DC 30V
Voltage - Rated 30VDC
Number of Positions 10
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 78
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Plastic
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
