78M12S
RoHS
/
Package /
Category Switches / DIP Switches
Description
Slide (Standard) 78 12 Through Hole Dip Switch 0.315 8.00mm 150mA 30VDC -40C~85C
PDF
/
Inventory: 7618
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2003
Series 78
Feature Tape Seal
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 12
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated 30VDC
Voltage - Rated DC 30V
Current Rating (Amps) 150mA
Pitch 0.100 2.54mm Full
Current Rating 150mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Electrical Life 2,000 Cycles
Throw Configuration SPST
Mechanical Life 2,000 Cycles
Washable Yes
Actuator Level Raised
Dimensions
Length 1.280 32.51mm
Height Above Board 0.315 8.00mm
Compliance
RoHS Status Non-RoHS Compliant
