78M08S
RoHS
/
Package /
Category Switches / DIP Switches
Description
Slide (Standard) 78 8 Through Hole Dip Switch 6.731mm 0.05A 750VRMS V 0.03mOhm
PDF
/
Buying Options
Total Price: USD $3.7
Unit Price: USD $3.6955
≥1 USD $3.6955
≥10 USD $3.0324
≥100 USD $2.9374
≥500 USD $2.8424
≥1000 USD $2.74835
Inventory: 1161
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height Above Board 0.315 8.00mm
Body Height 6.731mm
Length 0.880 22.35mm
Technical
Washability SOLVENT
Solderability MIL-STD
Actuator Level Raised
Washable Yes
Contact Function ON-OFF
PCB Hole Count 16
Contact Timing MAKE-BEFORE-BREAK
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 750VRMS V
Contact Current(DC)-Max 0.05A
Insulation Resistance 5000000000Ohm
Contact Resistance 0.03mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 9.652 mm
Termination Style PC Pin
Contact Finish Gold
Current Rating 150mA
Reach Compliance Code unknown
Pitch 0.100 2.54mm Full
Voltage - Rated DC 30V
Voltage - Rated 30VDC
Terminal Finish TIN-LEAD/NICKEL
Number of Positions 8
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Tape Seal
Series 78
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
