78J03SRAT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP N.O./N.C. SPDT 3 Raised Slide 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $16.73
Unit Price: USD $16.731598
≥1 USD $16.731598
≥195 USD $6.676097
≥495 USD $6.452904
≥1005 USD $6.34262
Inventory: 4761
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.380 9.64mm
Length 0.680 17.27mm
Technical
Actuator Level Raised
Washable Yes
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Electrical Life 10,000 Cycles
Max Current Rating 150mA
Circuit SPDT
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 150mA
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 30V
Voltage - Rated 30VDC
Number of Positions 3
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tape Seal
Series 78
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Plastic
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
