78J01ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP N.O./N.C. SPDT 1 Raised Slide 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $4.87
Unit Price: USD $4.8664
≥1 USD $4.8664
≥10 USD $4.44224
≥100 USD $4.040203
≥500 USD $3.490335
≥1000 USD $3.173025
≥3000 USD $2.940326
Inventory: 798
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2010
Series 78
Feature Tape Seal
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Number of Positions 1
Voltage - Rated 30VDC
HTS Code 8536.50.90.65
Voltage - Rated DC 30V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Depth 9.65mm
Current Rating 150mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPDT
Max Current Rating 150mA
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 1
Washable Yes
Actuator Level Raised
Dimensions
Length 0.280 7.11mm
Body Height 6.22mm
Actuator Length 1.27mm
Height Above Board 0.315 8.00mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
