78HJ02GWRT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP ON OFF SPDT 2 Raised Slide 0.15A 30VDC Gull Wing 2000Cycles/SwitchCycles 2.54mm SMD T/R
PDF
/
Buying Options
Total Price: USD $9.72
Unit Price: USD $9.723337
≥1 USD $9.723337
≥200 USD $3.87962
≥500 USD $3.749642
≥1000 USD $3.686623
Inventory: 6576
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2010
Series 78H
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Termination Gull Wing
ECCN Code EAR99
Number of Positions 2
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Voltage - Rated 30VDC
HTS Code 8536.50.90.65
Voltage - Rated DC 30V
Pitch 0.100 2.54mm Full
Packing Method TAPE AND REEL
Orientation Straight
Current Rating 150mA
Contact Finish Gold
Termination Style Gull Wing
Body Breadth 9.65 mm
Actuator Type Slide (Standard)
Circuit SPDT
Contact Current(DC)-Max 0.15A
Max Current Rating 150mA
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 2
Washable No
Actuator Level Raised
Dimensions
Length 0.480 12.19mm
Body Height 6.81mm
Height Above Board 0.327 8.30mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
