78B10
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 150MA 30V
PDF
/
Inventory: 5596
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Above Board 0.315 8.00mm
Actuator Length 1.27mm
Body Height 6.22mm
Length 1.080 27.43mm
Technical
Washability SOLVENT
Solderability HAND
Actuator Level Raised
Washable No
Contact Function ON-OFF
PCB Hole Count 20
Number of Switch Sections 10
Contact Timing BREAK-BEFORE-MAKE
Switch Type SLIDE DIP SWITCH
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Contact Current(DC)-Max 0.15A
Contact Resistance 0.1mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 9.65 mm
Termination Style PC Pin
Contact Finish Gold
Current Rating 150mA
Terminal Pitch 2.54mm
Orientation Straight
Packing Method TAPE AND REEL
Pitch 0.100 2.54mm Full
Voltage - Rated DC 30V
HTS Code 8536.50.90.65
Voltage - Rated 30VDC
Terminal Finish TIN LEAD
Number of Positions 10
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series 78
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 9 Weeks
