76RSB06SLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP ON OFF SPST 6 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $10.34
Unit Price: USD $10.335149
≥1 USD $10.335149
≥195 USD $4.123819
≥495 USD $3.985964
≥1005 USD $3.917694
Inventory: 6013
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.292 7.41mm
Length 0.680 17.27mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Throw Configuration SPST
Electrical Life 2,000 Cycles
Max Current Rating 150mA
Circuit SPST
Actuator Type Rocker
Termination Style PC Pin
Contact Finish Gold
Current Rating 150mA
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 150mA
Voltage - Rated DC 30V
Voltage - Rated 30VDC
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 6
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Position Identification Line, Tape Seal
Series 76
Published 2015
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
