76RSB06LT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Rocker 76 6 Through Hole Dip Switch 0.292 7.41mm 150mA 30V -40C~85C
PDF
/
Buying Options
Total Price: USD $9.91
Unit Price: USD $9.908456
≥1 USD $9.908456
≥195 USD $3.954455
≥495 USD $3.821852
≥1005 USD $3.756207
Inventory: 6399
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2015
Series 76
Feature Position Identification Line
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Number of Positions 6
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated 30VDC
Voltage - Rated DC 30V
Current Rating (Amps) 150mA
Pitch 0.100 2.54mm Full
Orientation Straight
Current Rating 150mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Rocker
Circuit SPST
Max Current Rating 150mA
Electrical Life 2,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 30V
Mechanical Life 2,000 Cycles
Washable No
Actuator Level Flush, Recessed
Dimensions
Length 0.680 17.27mm
Height Above Board 0.292 7.41mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
