76RSB02S

Grayhill Inc.
RoHS
/
Package /
Category Switches / DIP Switches
Description SWITCH ROCKER DIP SPST 150MA 30V
PDF
/
Inventory: 6806
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Termination Style PC Pin
Body Breadth 7.1 mm
Actuator Type Rocker
Circuit SPST
Contact Resistance 0.1mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 0.15A
Dielectric Withstanding Voltage 500VAC V
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Contact Timing MAKE-BEFORE-BREAK
Number of Switch Sections 2
PCB Hole Count 4
Contact Function ON-OFF
Washable Yes
Actuator Level Flush, Recessed
Solderability WAVE
Washability SOLVENT
Contact Finish Gold
Current Rating 150mA
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 30V
HTS Code 8536.50.90.65
Voltage - Rated 30VDC
Number of Positions 2
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Tape Seal
Series 76
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C

Dimensions

Length 0.280 7.11mm
Body Height 6.91mm
Actuator Length 0m
Height Above Board 0.292 7.41mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead

Physical

Body Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 9 Weeks
