76PSB08ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
GRAYHILL 76PSB08ST DIP / SIP Switch, 76 Series, SPST, Through Hole, 8 Circuits, DIP Sealed, 30 VDC
PDF
/
Buying Options
Total Price: USD $4.39
Unit Price: USD $4.3912
≥1 USD $4.3912
≥10 USD $4.0128
≥100 USD $3.6498
≥500 USD $3.153005
≥1000 USD $2.866389
≥3000 USD $2.656183
Inventory: 1150
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Above Board 0.301 7.65mm
Body Height 7.14mm
Length 0.880 22.35mm
Technical
Actuator Level Raised
Washable Yes
Number of Switch Sections 8
Contact Current Rating 150mA
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Electrical Life 2,000 Cycles
Max Current Rating 150mA
Contact Current(DC)-Max 0.15A
Insulation Resistance 5GOhm
Contact Resistance 30mOhm
Circuit SPST
Lead Length 3.96mm
Actuator Type Piano
Termination Style PC Pin
Contact Finish Gold
Current Rating 150mA
Depth 9.65mm
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 30V
Capacitance 5pF
Voltage - Rated 30VDC
Number of Positions 8
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Tape Seal
Series 76
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Thermoplastic
Mounting Type Through Hole, Right Angle
Mount PCB, Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
