76PSB04
RoHS
/
Package /
Category Switches / DIP Switches
Description
Piano 76 4 Through Hole Right Angle Dip Switch 0.301 7.65mm 0.15A 500VAC V 0.1mOhm
PDF
/
Buying Options
Total Price: USD $2.02
Unit Price: USD $2.017927
≥1 USD $2.017927
≥210 USD $0.806121
≥525 USD $0.77855
≥1050 USD $0.765421
Inventory: 5299
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Above Board 0.301 7.65mm
Length 0.480 12.19mm
Technical
Washability SOLVENT
Solderability HAND
Actuator Level Raised
Washable No
Contact Function ON-OFF
PCB Hole Count 8
Number of Switch Sections 4
Contact Timing MAKE-BEFORE-BREAK
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Sealing EPOXY TERMINAL SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.15A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.1mOhm
Circuit SPST
Actuator Type Piano
Body Breadth 9.65 mm
Termination Style PC Pin
Contact Finish Gold
Current Rating 150mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 30V
Voltage - Rated 30VDC
Terminal Finish Tin/Lead (Sn/Pb)
Number of Positions 4
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series 76
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Thermoplastic
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 9 Weeks
