76MPSB05S
RoHS
/
Package /
Category Switches / DIP Switches
Description
Piano 76 5 Through Hole Right Angle Dip Switch 0.301 7.65mm 150mA 30VDC -40C~85C
PDF
/
Buying Options
Total Price: USD $3.12
Unit Price: USD $3.124702
≥1 USD $3.124702
≥198 USD $1.247255
≥504 USD $1.205242
≥1008 USD $1.184236
Inventory: 7336
Minimum: 1
-
+
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2003
Series 76
Feature Tape Seal
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 5
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated 30VDC
Voltage - Rated DC 30V
Current Rating (Amps) 150mA
Pitch 0.100 2.54mm Full
Current Rating 150mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Piano
Circuit SPST
Electrical Life 2,000 Cycles
Throw Configuration SPST
Mechanical Life 2,000 Cycles
Washable Yes
Actuator Level Raised
Dimensions
Length 0.580 14.73mm
Height Above Board 0.301 7.65mm
Compliance
RoHS Status Non-RoHS Compliant
